Honor Series Genetic Analyzer
Product Details
Model: Honor1616、1816、1624、1824、1696

Honor series genetic analyzer has been the earlier product of Superyears Company, and it has made a breakthrough by creating 8-color fluorescence technology instead of using the traditional 6-color fluorescence, which can detect up to 70 STR loci, and it is able to complete database construction through a single test together with autosomes and Y-chromosomes. In addition, the genetic analyzer can be applied in gene sequencing and fragment analysis, and it is able to provide a customized operational Interface and Software, which provide a reliable technology platform for criminal investigation and judicial appraisal.


Basic Parameters

Size (L x W x H) Doors Closed: 610×532×812 mm
Doors Opened: 1225×532×812mm
Weight 95 KG (approx.)
Channel 8、16、24、96
Fluorescence Dye 6、8
Capillary Length 36 cm 、50 cm
Sampling Method Auto-Sampling, Compatible with 96-well plate (x2) and 8-strip tubes
Polymer-Injection Method Auto-Polymer Injection
Laser Solid-state semiconductor
Laser wave length 505 nm
Fluorescence Dye wave length > 520 nm

Consumable reagent

Consumable Reagent Specification Model Unit Code
16-Channel Capillary tube 36 cm set SY01C001
16-Channel Capillary Capillary Array 50 cm set SY01C002
24-Channel Capillary tube 36 cm set SY01C017
24-Channel Capillary Capillary Array 50 cm set SY01C018
10x buffer 500 ml Bottle SY01C10
HD formamide 25 ml Bottle SY01C008
SY04 Polymer 3.5 ml Bottle SY01C005
SY07 Polymer 28 ml Bottle SY01C006



Y62Plex STR Kit is provided by Jiangsu Superbio Biomedical Co., LTD. Y62Plex fluorescence detection kit adopts eight-color fluorescence and fluorescence energy resonance transfer technology, simultaneously amplifies 62 loci. Including all 35 loci, 25 alternative loci and 2 Y chromosome Indel in the core and optimal standard of Y chromosome construction, high-quality Y chromosome STR construction can be completed within one reaction, which can improve the construction efficiency and reduce the construction cost.
